| Place of Origin: | NINGBO,CHINA |
| Brand Name: | BUFFALO |
| Model Number: | 2344638/234-4638 |
| Minimum Order Quantity: | 1PCS |
|---|---|
| Packaging Details: | in carton |
| Delivery Time: | in stock |
| Payment Terms: | T/T, Western Union, paypal |
| Pos. | Part No | Qty | Parts name | |
|---|---|---|---|---|
| 1. | 8T-9597 | [1] | RING-RETAINING | |
| 2. | 185-0303 | [1] | SEAL-OIL | |
| 3. | 271-6432 | [1] | BEARING AS-TAPERED ROLLER | |
| 4. | 155-9122 | [1] | SWASHPLATE | |
| 5. | 295-9552 | [1] | HOUSING | |
| 6. | 191-7582 | [1] | SHIM (2.5-MM THK) | |
| 7. | 191-7583 | [1] | BEARING-TAPERED | |
| 8. | 295-9553 | [1] | COVER | |
| 9. | 8T-0341 M | [4] | BOLT-SOCKET HEAD (M10X1.5X60-MM) | |
| 10. | 9X-8979 | [1] | DOWEL | |
| 11. | 231-4707 | [1] | SEAL-O-RING | |
| 12. | 233-2530 Y | [1] | ROTATING GP-MOTOR (HYDRAULIC FAN) | |
| 13. | 9S-8005 | [1] | PLUG (3/4-16-THD) | |
| 14. | 3K-0360 | [1] | SEAL-O-RING | |
| 15. | 9X-6419 | [2] | DOWEL | |
| 16. | 194-9473 | [1] | RING | |
| 17. | 295-9554 | [1] | SHAFT-DRIVE | |
| 18. | 197-2471 | [1] | PLUG AS | |
| 197-2472 | [1] | SEAL | ||
| 19. | 295-9555 | [1] | SLEEVE | |
| 20. | 197-2474 | [1] | VALVE AS | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
