416 428 pump 9T6857 repair parts overhaul kit

Place of Origin:	Ningbo,China
Brand Name:	buffalo

Contact Now

Detailed Product Description

Pos.	Part No	Qty	Parts name
1.	9T-2002	[1]	GASKET
2.	5F-9144	[1]	SEAL-O-RING
3.	7L-0688	[4]	BOLT-SOCKET HEAD
4.	9T-6859 Y	[1]	VALVE GP-PRESS & FLOW CMPNSTR
5.	9T-2172	[1]	PISTON
6.	9T-2170	[1]	ROD-PISTON
7.	9S-4190	[1]	PLUG-0-RING
8.	2M-9780	[1]	SEAL-O-RING
9.	8F-9206	[1]	SEAL-O-RING
10.	9T-2003	[1]	RING
11.	9T-2000 B	[1]	KIT-SPACER
12.	9T-2232	[1]	PLATE-WAFER
13.	7T-9752	[1]	CONE-ROLLER BEARING
14.	7T-9753	[1]	CUP-ROLLER BEARING
15.	9T-1752	[1]	GASKET
16.	8T-5089	[2]	PIN-SPRING
17.	9T-2001	[1]	PIN
18.	9T-2176	[1]	HEAD-VALVE BLOCK
19.	9T-2016	[1]	SHAFT
20.	9T-3867	[1]	SPRING
21.	5P-0076	[6]	BOLT-12 POINT HEAD
22.	9T-2168	[1]	SPRING
23.	9T-2171	[1]	SEAT
24.	9T-2173	[1]	SEAT
25.	8J-8308	[1]	PIN-ROLL
26.	002-3455	[1]	RING-RETAINING
27.	3E-6748	[1]	SEAL-LIP TYPE
28.	9T-2015	[1]	HOUSING
29.	7T-9755	[1]	CUP-ROLLER BEARING
30.	7T-9754	[1]	CONE-ROLLER BEARING
31.	9T-2231	[1]	SWASHPLATE
32.	7T-9831	[2]	CONE-ROLLER BEARING
33.	3P-8680	[2]	CUP-ROLLER BEARING
34.	9T-2017	[2]	SPACER
35.	005-8593	[2]	SEAL-O-RING
36.	9T-2011 B	[1]	KIT-SHIM
37.	9T-2014	[2]	COVER
38.	9S-2011	[8]	SCREW-MACHINE
39.	9F-2247	[1]	PLUG
40.	9T-1636	[1]	SEAT
41.	9T-1710	[1]	POPPET
42.	9T-2031	[1]	ROTATING GP
43.	9T-3868	[1]	KIT-PISTON
44.	9T-3860	[1]	PLATE
45.	9T-3859	[1]	WASHER-SPHERICAL
46.	9T-3862	[1]	RETAINER
47.	9T-3857	[3]	PIN
48.	9T-3863	[1]	BARREL
49.	9T-3861	[1]	WASHER
50.	9T-3858	[1]	SPRING
51.	9T-3864	[1]	WASHER
52.	004-1683	[1]	RING-SNAP
